Practical Small Excavator Sells FR260E-HD 169KW 26TON with Excavator Buckets for Sell
PRODUCT DESCRIPTIONThe FR260E-HD excavator uses the core components of the original international famous brand to make the product more reliable. Engines, main pumps, main valves, swing motors, walking motors, controllers, etc. all adopt first-class resource allocation in the industry.
Automatic idle speed, the engine will automatically adjust to automatic idle speed if the whole machine has no action for more than 10 seconds, further reducing fuel consumption.
The engine adopts electronically controlled high-pressure common rail technology, multiple injections can be precisely controlled and fuel economy improved by 15%.
Enlarge the internal passage of the main valve, thicken the pipeline diameter, optimize the pipeline direction, reduce the
hydraulic loss along the way, and reduce the hydraulic system energy loss by 5%.
New 5.7-inch flat-panel ultra-thin LCD instrument information review is clearer.
By optimizing and improving noise and vibration sources, noise is reduced and driving comfort is improved.
The engine core parts are guaranteed for up to 5 years/10000 hours, which is safe and worry-free.
Performance characteristics
The new high-power engine meets the requirements of China's third-stage emission standards, with strong power and higher fueleconomy.Automatic idle speed, the engine will automatically adjust to automatic idle speed if the whole machine has no action for more than 10 seconds, further reducing fuel consumption.
The engine adopts electronically controlled high-pressure common rail technology, multiple injections can be precisely controlled and fuel economy improved by 15%.
Enlarge the internal passage of the main valve, thicken the pipeline diameter, optimize the pipeline direction, reduce the
hydraulic loss along the way, and reduce the hydraulic system energy loss by 5%.
New 5.7-inch flat-panel ultra-thin LCD instrument information review is clearer.
By optimizing and improving noise and vibration sources, noise is reduced and driving comfort is improved.
The engine core parts are guaranteed for up to 5 years/10000 hours, which is safe and worry-free.
Machine parameters | Engine | |||
Total length | mm | 9925 | model | Cummins/ QSB7 |
Grounding length (transport) | mm | 5600 | Type | In-line, EFI, supercharged, intercooled |
Total height (to the top of boom) | mm | 3400 | Rated power kW/rpm | 169 /2050 |
Total width | mm | 3180 | Maximum torque N·m | 800/110 |
Total height (to the top of the cab) | mm | 3080 | Walking drive | |
Counterweight ground clearance | mm | 1090 | Maximum gradeability ° | 35 |
Minimum ground clearance | mm | 443 | Maximum walking speed km/h | 5.3 |
Radius of tail gyration | mm | 2920 | main traction force | 206 |
Track ground length | mm | 3845 | Maintenance filling capacity | |
Track length | mm | 4640 | Diesel fuel L | 385 |
gauge | mm | 2580 | Total hydraulic oil of hydraulic system L | 260 |
Track width | mm | 3180 | Hydraulic oil tank volume L | 220 |
Track shoe width | mm | 600 | Engine oil L | 23.5 |
Tooth height | mm | 16 | Engine coolant L | twenty two |
Machine cover height | mm | 2140 | Rotary reducer oil quantity L | 5.3 |
Upper platform width | mm | 2830 | Travel reducer oil quantity L | 5.3 x 2 |
Distance from center of rotation to back end | mm | 2920 | Hydraulic system | |
The scope of work | Maximum flow of main system L | 2x299 | ||
Maximum digging height | mm | 9940 | Maximum pressure of working oil MPa | 37.3 |
Maximum unloading height | mm | 7010 | Maximum pressure of pilot system | 3.9 |
Maximum digging depth | mm | 6710 | Slewing mechanism | |
Maximum vertical digging depth | mm | 5740 | Rotation speed r/min | 11.5 |
Horizontal cutting 8′ maximum digging depth | mm | 6525 | Rotating moment kN·m | 83 |
Maximum digging radius | mm | 10000 | Machine parameters | |
Maximum digging radius on the ground | mm | 9860 | Working weight kg | 25800 |
Minimum radius of gyration | mm | 3270 | Bucket capacity m3 | 1.2-1.35 |
Dozer descent depth | mm | 295 | Stick digging force kN | 128 |
Dozer blade lifting height | mm | 375 | Bucket digging force | 169 |
